Quick Release couplers

1.Metal Quick-Acting Couplers

• Material: Made from nickel-plated brass or stainless steel for durability and corrosion resistance.

• Applications: Suitable for compressed air, water, and industrial fluids.

• Pressure Range: Handles up to 35 bar (stainless steel) and 20 bar (brass).

• Temperature Range: Operates between -15°C to +200°C (stainless steel) and -20°C to +100°C (brass).

2. Single Shut-Off Couplers

• Functionality: Stops fluid flow in the female coupler when disconnected, ensuring safety.

• Applications: Ideal for systems requiring controlled disconnection to prevent fluid loss.

3. Double Shut-Off Couplers

• Functionality: Prevents flow on both sides (upstream and downstream) after disconnection.

• Applications: Ensures safety and prevents fluid leakage in high-pressure systems.

4. Straight-Through Couplers

• Functionality: Offers maximum flow without shut-off, suitable for fluids like water and coolants.

• Applications: Requires upstream valves to control fluid flow before disconnection.

5. Non-Spill Couplers

• Feature: Designed to minimize fluid spillage during connection and disconnection.

• Applications: Ideal for hydraulic and pneumatic systems where cleanliness is critical.
